Specs
Length (including wing): | 23.78 inches (604 mm) |
---|---|
Front Track: | 18.10 inches (459 mm) |
Rear Track: | 18.10 inches (459 mm) |
Ground Clearance: | 1.95 inches (50 mm) |
Weight (no battery): | 12.74 pounds (5.77kgs) |
Height (overall): | 8.43 inches (214 mm) |
Wheelbase: | 15.10 inches (384 mm) |
Shock Length (front): | 5.12 inches (128 mm) |
Shock Length (rear): | 5.67 inches (144 mm) |
Tire Diameter: | 6.7 x 3.3 inches (170 mm x 84 mm) |
Wheel Diameter: | 3.8 inches (97 mm) |
Speed Control: | Velineon® VXL-6s (3485) |
Motor (electric): | Velineon® 2000 kV Brushless |
Overall Drive Ratio: | 17.2 (13/52 motor pinion and spur gear) |
Differential Type: | Sealed, hardened steel bevel, limited slip |
Gear Pitch: | Module 1.0 |
---|---|
Chassis Structure/Material: | 3.2 mm aluminum plate |
Brake Type: | Electronic |
Drive System: | Shaft-driven 4WD |
Steering: | Double-shear bellcrank w/metal servo arm |
Wheels & Tires: | 3.8″ wheels, pre-glued belted Sledgehammer® Tires & foam inserts; 6.7x3.8 |
Radio System: | 2-Channel, TQi™ 2.4 GHz Transmitter with TSM® receiver |
Servo: | 2275 Waterproof, metal-gear (347 oz-in torque) |
Top Speed: | 70+ MPH with two 3s LiPo batteries and optional gearing (sold separately) |
Skill Level: | 4 |
Battery Tray: | Narrow configuration (L/W/H): 181 mm x 50 mm x 29/37/45 mm* Wide configuration (L/W/H): 160 mm x 57 mm x 29/37/45 mm* |
Required Batteries: | 4 “AA” (transmitter), Vehicle (see battery finder) |
What’s In The Box:
- Sledge, Ready-To-Race® monster truck with Traxxas 2000 kV brushless motor
- VXL-6s waterproof electronic speed control with integrated telemetry
- Quick Start Guide
- TQi 2.4 GHz radio system
- High quality maintenance tools
- Jumper plug (for 4s battery use)
What You’ll Need:
- LiPo Batteries
Traxxas recommends dual 5000 mAh 3-cell 11.1 V Power Cell LiPo batteries for maximum performance. Dual 7600 mAh 7.4 V LiPo batteries or a single 6700 mAh 14.8 V LiPo battery will operate the vehicle with reduced performance. NiMH batteries are not supported.
- LiPo Balance Charger with iD™
Traxxas EZ-Peak® Live 4s-capable charger is recommended for easy and fast charging performance (model #2971).
- AA Alkaline Batteries
Four AA alkaline batteries for the transmitter.
