Veermiku spetsifikatsioon
Pikkus: | 262mm (Bronco) 279mm (Defender) |
---|---|
Rööbe ees: | 124mm |
Rööbe taga: | 124mm |
Kliirens: | 29mm |
Mass(ilma akuta): | 468g (Bronco) 483g (Defender) |
Kõrgus: | 117mm (Bronco) 135mm (Defender) |
Teljevahe: | 155mm |
Lähenemisnurk: | 54° (Bronco) 52° (Defender) |
Kõõlumisnurk: | 45° (Bronco) 45° (Defender) |
Eemaldumisnurk: | 48° (Bronco) 41° (Defender) |
Amordi pikkus (ees ja taga): | 51mm |
Rattahex: | 7mm |
Veljed (ees ja taga): | 1.0 x 0.49 tolli (25.4 x 12.5mm) |
---|---|
Rehvid (ees ja taga): | 2.2 x 1.0 tolli (57 x 25.4mm) |
Elektrooniline kontrollmoodul (ECM): | ECM-2.5™ (kombo ESC, vastuvõtja, LEDide juhtimine*) |
Mootor: | Titan® 180 87T harjadega elektrimootor |
Difrid: | Pideva lukustusega; 2:1 silla ülekanne |
Raami tüüp ja materjal: | Terasest redelraami railid, plastikust vahedetailid |
Pidurid: | Elektroonilised mootoriga, mäepiduri funktsiooniga |
Veoskeem: | Kardaanidega pidev 4WD |
Roolisüsteem: | Sillale paigaldatud servo |
Raadiosüsteem: | TQ™ 2.4GHz 2-kanaliga saatja |
Servo: | #2065T |
Oskuste tase: | 1 |
Aku pesa: | 50.5 x 31mm |
* LED kit müügil eraldi (Pro Scale LED Light Kit) |
Mootori Spetsifikatsioon
Tüüp: | Harjadega mootor, väändele tuunitud |
---|---|
Surus: | 180 |
Mass: | 33g |
Mõõdud: | Üldpikkus 42mm, kannu pikkus 34mm, diameeter 21mm |
Keerud: | 87T reverse rotation |
Pinge: | 8.4V |
ECM spetsifikatsioon
Sisendpinge: | 2s LiPo |
---|---|
Korpuse mõõdud: | 32 x 46 x 15 mm |
Mass: | 26g |
BEC pinge: | 6.0 VDC |
BEC voolutugevus: | 1A |
LiPo cutoff (LVD): | 2-astmeline |
Transistorite tüüp: | MOSFET |
---|---|
Mootori ülekoormuskaitse: | 2-astmeline |
Profiilid: | Sport Mode: 100% edasi, 100% pidurid, 100% taurpidi Trail Mode: 100% edasi, 100% pidur, 100% tagurpidi, Trail-Tuned pidur neutraalasendis Crawl Mode: 100% edasi, 100% kohene tagurpidi, 100% pidur neutraalasendis |
Features
- Clipless ABS Body
- Highly-detailed licensed bodies
- Molded-in color won’t chip or flake
- Tough fender flares and rock sliders
- Realistic side mirrors, door handles, & wipers
- LED bumper lights
- Heavy-duty latching clips
- Hold tightly on the trail
- Release in just seconds
- Highly-detailed licensed bodies
- ECM-2.5™ Electronic Control Module
- Incorporates ESC, receiver, and LED controller in one chassis
- Fully waterproof for all-weather fun
- Three drive profiles
- Sport Mode – forward / brake / reverse
- Trail Mode – forward / brake / reverse / with trail-tuned drag brake in neutral
- Crawl Mode – forward / instant reverse - no neutral with 100% hill holding brake
- Traxxas EZ-Set® one-button setup
- Built-in Pro Scale® LED functionality
- Two-stage low voltage protection (LVD)
- Motor overload protection
- TQ™ 2.4GHz Transmitter
- Full-size 2-channel transmitter
- All-day comfort with precise long-range control
- Motor
- Powerful Titan® 87-turn brushed motor
- Fixed gear mesh doesn’t require adjustment
- Forward mounting position for improved crawling dynamics
- Heavy-Duty Steel Ladder Frame
- Deep C-channel design
- Thicker center section for maximum rigidity
- Rails run from bumper to bumper
- Drivetrain
- Full-time shaft-driven 4-wheel drive
- Solid steel axles
- Spool-equipped front and rear axles
- Heavy-duty CV center driveshafts
- Low-CG Battery Tray
- Concentrates weight lower for improved stability
- Wide rubber strap secures battery in place
- Optional Transmission Ratios (sold separately)
- Optional Low Range or Speed Gearing transmissions
- Modular design swaps out in minutes
- Optional Low Range or Speed Gearing transmissions
- Steering
- Heavy-duty 2065T steering servo
- Metal main gear
- Superior 45° steering angle
- Direct steering (no servo saver)
- Heavy-duty 2065T steering servo
- Suspension
- Triangulated 4 link front and rear
- Heavy-duty rod ends
- Oil-Filled GTM™ Shocks
- Provides smooth controlled damping
- Realistic driving body movements
- Adjustable pre-load spacers
- Easily refreshed with available rebuild kits
- Wheels and Tires
- Highly-detailed 1" Replica wheels
- 7mm hex
- Pre-mounted tires
- BF-Goodrich® Mud Terrain T/A® KM3 (Bronco)
- Canyon AT (Defender)
- Trail-tuned rubber compound
- Highly-detailed 1" Replica wheels
- Battery and Charger Included
- High-capacity 2-cell LiPo battery
- 7.4 volts
- 750mAh for over an hour of run time
- 2-amp USB-powered fast charger
- iD® technology for faster, safer charging
- High-capacity 2-cell LiPo battery
- Low-Maintenance Self-Lubricating Bushings
- Durable Hex hardware
Komplektis on:
- TRX-4M® sõiduvalmis mudel
- Litsentseeritud ABS kõvakere
- Titan® 180 87T harjadega mootor
- ECM-2.5™ Elektrooniline kontrollmoodul
- TQ saatja
- 7.4 V 750mAh 2S LiPo aku
- 2A USB laadija iD®
- Mõned tööriistad mudeli hooldamiseks
Lisaks vajad:
- AA patareid saatjasse (4 tk)
